ELRS Receiver Comparison

Disclaimer:
I am completely independent from any manufacturer of FPV products or company in the fpv space. These are my personal recommendations based on my experiences. I do not receive any compensation for these recommendations. I am not responsible for any damage or injury that may occur from following my recommendations. Please use common sense and be safe.

2.4 GHz

Model Manufacturer Size Weight Antenna Telemetry Power PA/LNA Diversity TCXO
BetaFPV Nano BetaFPV Nano, 12x19mm 0.7 g External 100 mW Yes No N/A
BetaFPV SuperD BetaFPV 22x14mm 1.1 g External 100 mW Yes True Diversity Yes
BetaFPV Lite Tower BetaFPV PP, 10x10x6mm 0.47 g SMD/Ceramic, Tower Style 17 mW No No N/A
BetaFPV Lite Flat BetaFPV PP, 10x10x3mm 0.53 g SMD/Ceramic, Flat 17 mW No No N/A
BetaFPV Micro BetaFPV 19x32mm 3.5 g External 17 mW No No N/A
GEPRC ELRS 2.4G Dual GEPRC 20 x 14mm 1.2 g External 100 mW Yes True Diversity Yes
GEPRC ELRS Nano 2.4G PA100 GEPRC Nano, 17x11mm 0.7 g External 100 mW Yes No Yes
GEPRC Nano GEPRC Nano, 16.8mm*10mm 0.6 g External 17 mW No No No
GEPRC ELRS NanoSE GEPRC PP, 12.1mm*10.4mm 0.4 g Onboard, Tower style 17 mW No No No
Happymodel EP1 Happymodel PP, 10x10mm 0.44 g External N/A N/A No No
Happymodel PP Happymodel PP, 10x10mm 0.47 g SMD/Ceramic N/A No No No
Happymodel EP2 Happymodel PP, 10x10mm 0.42 g SMD/Ceramic N/A No No No
Happymodel EP1 TCXO Happymodel PP, 10x10mm 0.41 g External N/A N/A No Yes
Happymodel EP1 Dual TCXO Happymodel 19x14mm 1 g External N/A N/A True Diversity Yes
Happymodel EP2 TCXO Happymodel PP, 10x10mm 0.44 g SMD/Ceramic N/A N/A No Yes
Radiomaster RP1 V2 Radiomaster PP, 13x11mm 0.53 g External 10 mW No No Yes
Radiomaster RP2 Radiomaster PP, 13x11mm 0.55 g SMD/Ceramic 10 mW No No Yes
Radiomaster RP3 V2 Radiomaster 22x13mm N/A External 100 mW Yes Antenna Diversity Yes
Radiomaster RP4DT Radiomaster 16.3x23.7mm 1.4 g External 100 mW Yes True Diversity Dual
iFlight True Diversity iFlight 24.5x18.6mm 3.3 g External 250 mW Yes True Diversity Yes
iFlight Nano iFlight PP, 10x13 mm 0.5 g External 17 mW No No No
iFlight Nano SMD Antenna iFlight PP, 10x13 mm 0.5 g SMD/Ceramic, Tower Style 17 mW No No No

900 MHz

All “900 MHz” Hardware is capable of 868Mhz and 915 MHz. Generally it is referred to as 900MHz. As 900 MHz uses a bigger Antenna format there is no column for Antenna Type. The Antenna is external in every case.

Model Manufacturer Size Weight Telemetry Power PA/LNA Diversity TCXO
BetaFPV Nano BetaFPV Nano 0.7 g 100 mW Yes No N/A
BetaFPV SuperD BetaFPV 22 x 14mm 1.2 g 100 mW Yes True Diversity Yes
GEPRC Nano 915M V2 GEPRC Nano, 17x11mm 0.7 g 50 mW No No Yes
GEPRC ELRS DUAL 915M Diversity GEPRC 18x25mm 1.7 g 50 mW No True Diversity Yes
Happymodel ES900 DUAL RX Happymodel 21.5x16mm 1.5 g 50 mW No True Diversity Yes
Radiomaster BR1 Radiomaster 18x13.8mm (Nano) N/A 50 mW No No Yes
Radiomaster BR3 Radiomaster 24x14.2mm N/A 500 mW Yes Antenna Diversity Yes
iFlight True Diversity iFlight 24.3x18.5 4.2 g 500 mW Yes True Diversity Yes
iFlight Nano iFlight Nano, 10 x 13 mm 0.5 g 50 mW No No No
